Our sweeper superstructure from the 6 m³ sweeper series has very low noise emissions due to the upward exhaust air routing.
Container sizes range from 6 m³ to 10 m³ and are mounted on vehicles with a wheelbase of at least 3260 mm. Alternatively, it can be driven by an auxiliary engine that complies with the current emissions standard or by a hydraulic system driven by the vehicle’s power take-off. All relevant systems are controlled via a CAN bus system.
As usual, the entire sweeper superstructure is also available as a quick-change system in order to achieve maximum utilization of the carrier vehicle throughout the year.
The road sweeper can be offered as a single-sided or dual version, with many optional extras available for optimum road cleaning.
Requires mandatory technical equipment!
TK6000
Standard Sweeper Attachment with a waste-hopper volume of 6.0 m³ and integrated 1600 l watertank, made of stainless steel,
optional DUAL-Version (additional left brush-unit)
High-performance suction-fan with a power of max. 13,000 m³/h at max.
3,300 min-1
TK7000
Sweeper superstructure, 7.0 m³ dirt container and
integrated 2,000 l water tank, made of stainless steel,
optional additional left sweeping unit for DUAL version,
optional more powerful S-fan with max. 18,000 m³/h at max. 3,300 min-1
TK9000
Sweeper superstructure, 9.0 m³ dirt container and integrated water tank approx. 2,500 l, made of stainless steel
Optional additional water tank 2,500 litres, made of stainless steel
Right-hand sweeping unit
optional S-fan with max. 18,000 m³/h at max. 3,300 min-1
Optional fold-out front wash bar and hose reel
-
- TK9000 with rear suction unit
-
- Extandable plate scraper
-
- Swivelable front brush
-
- Extandable front brush
-
- Front brush with extandable washing bar
-
- TK6000 with rear suction unit
